Installing Keras for deep learning

install_keras_header

The purpose of this blog post is to demonstrate how to install the Keras library for deep learning. The installation procedure will show how to install Keras:

  • With GPU support, so you can leverage your GPU, CUDA Toolkit, cuDNN, etc., for faster network training.
  • Without GPU support, so even if you do not have a GPU for training neural networks, you’ll still be able to follow along.

Let me start by saying that Keras is my favorite deep learning Python library. It’s a minimalist, modular neural network library that can use either Theano or TensorFlow as a backend.

Furthermore, the primary motivation behind Keras really resonates with me: you should be able to experiment super quickly — going from idea to result, as fast as possible.

Coming from a world that mixes both academia and entrepreneurship, the ability to iterate quickly is extremely valuable, especially in the deep learning world where it can take days to weeks to train just a single model.

I’ll be using Keras extensively in the coming PyImageSearch blog posts, so make sure you follow this tutorial to get Keras installed on your machine!

Installing Keras for deep learning

I’ll be making the assumption that you’ve been following along in this series of blog posts on setting up your deep learning development environment:

I’ll be using my same Amazon EC2 g2.2xlarge instance running Ubuntu 14.04 as I have in previous tutorials — feel free to use the same machine you’ve been using to follow along as well.

Overall, installing Keras is a 5-step procedure, with three of these steps being optional.

The first optional step is whether or not you would like to use Python virtual environments — I suggest that you do, but that decision is entirely up to you.

The second optional step is whether or not you want to use the GPU to speedup training your neural networks — this is obviously dependent on whether you own a CUDA-compatible GPU. The Keras library can run on the CPU just fine, but if you really want to train deep neural networks, you’ll want to get a GPU installation setup.

The final optional step is whether or not you would like to have OpenCV bindings in your Python virtual environment along with your Keras installation. If you do, you’ll want to pay attention to Step #4.

With all that said, let’s get started!

Step #1: Create a separate Python virtual environment (optional)

If you’ve been following along in this series of posts, then you already know that I like using Python virtual environments. Utilizing virtual environments is especially important when we start working with various deep learning libraries (Keras, Theano, mxnet, TensorFlow, etc.) and versioning issues can easily occur (especially surrounding which version of Theano is used).

Because of the problems related to conflicting library versions, I suggest creating a virtual environment exclusively for Keras-based projects:

This will create a Python virtual environment named keras . Anytime you would like to access this virtual environment, just use the workon  command followed by the name of the virtual environment:

In this case, we can access the keras  virtual environment by executing the following command:

Step #2: Install Keras

Installing Keras is a breeze — pip  can do all the hard work for us. First, we need to install a few dependencies:

We also need to install Theano. You can certainly use pip  to install Theano; however, it’s important to note that Keras always uses the latest version of Theano, which is not always the version that is on PyPI. Thus, we should instead install Theano using the following command:

An alternative method to install Theano is to clone the repository from GitHub and use the setup.py  script:

From there, we can use pip  to install Keras as well:

After Keras has finished installing, you can verify the install by opening up a terminal, accessing the keras  virtual environment, and then importing the library (see Step #5 for an example on how to do this).

However, if you want to optimize Keras so that it uses your GPU, CUDA Toolkit, and cuDNN, you’ll want to proceed to Step #3.

Step #3: Edit your keras.json configuration file

In order for the ~/.keras/keras.json  file to be created you first need to import keras  into your Python shell. If you do not import Keras, then the keras.json  file will not be created and you will be unable to find it on your disk. To perform this initial import of Keras simply open up a shell, (optionally) access the Python virtual environment (if you are using virtual environments), and then import Keras:

If you see any errors importing Keras, that’s okay — they are likely related to your configuration which we will resolve in the paragraphs directly below.

After performing the steps above you should now have a ~/.keras/keras.json  file in your home directory. Open this file using your favorite text editor and inspect the contents. The default configuration will look something like this:

Looking at the configuration we can see that TensorFlow is being used as the default backend. However, since we are using Theano instead of TensorFlow, we need to update our keras.json  file to reflect this (otherwise, you’ll receive an import error regarding TensorFlow not being found when you try to use Keras).

First, we need to change image_dim_ordering  from tf  to th , indicating that we want to use Theano image dimension ordering rather than TensorFlow.

The second update is to change the backend  from tensorflow  to theano (I’ll be covering how to use TensorFlow as a backend to Keras in a future blog post).

The updated  keras.json  file should look like this:

After making the required changes, save the keras.json  configuration file and exit your editor.

For those curious about the keras.json  file and how it is utilized to determine which backend to use (along with image dimension ordering), please refer to this page in the Keras documentation.

Step #4: Setup GPU support (only for GPU users)

Under the hood, Keras is using Theano as a backend — think of Keras is a wrapper around Theano to make it more user friendly (and easier to build deep neural networks).

In order to get Keras and Theano to utilize our GPU rather than the CPU, we need to create a file named .theanorc  in our home directory (if it does not already exist).

This file stores various configurations for the Theano library. You can supply these values via command line argument with the THEANO_FLAGS  variable; however, I find it more convenient to store global configurations inside the .theanorc  file.

Open up the .theanorc  file using your favorite command line text editor:

And then add the following lines to the file:

Save the file and then exit the editor.

Step #5: Sym-link in OpenCV (optional)

If you want to have access to your OpenCV bindings from the keras  virtual environment, you’ll need to sym-link in the cv2.so  file into the site-packages  directory of keras :

As I detailed in last week’s tutorial, after compiling and installing OpenCV, my cv2.so  bindings were found in /usr/local/lib/python2.7/site-packages/cv2.so . Depending on how you installed OpenCV on your own system, your cv2.so  bindings may be in a different location. If you cannot remember where your cv2.so  bindings are, or if you no longer have your CMake output (which does indicate where the bindings will be stored), you can use the find  utility program to help locate them:

Again, this is a totally optional step and only needs to be done if you want to have access to OpenCV from the keras  virtual environment.

Step #6: Test out the installation

To verify that Keras has been installed, access the keras  virtual environment, open up a Python shell, and import it:

Below follows a screenshot from my own EC2 instance:

Figure 1: Installing the Keras Python library for deep learning.

Figure 1: Installing the Keras Python library for deep learning.

Notice what when theano  is imported by keras , I’m given additional debugging information on the installation, such as the CUDA Toolkit and cuDNN v5 being utilized.

Also notice that the GPU is being used, in this case the K520 that is installed on the Amazon EC2 g2.2xlarge instance. For more information on how I installed the CUDA Toolkit and cuDNN, please see this blog post.

Optionally, if you performed Step #5 and want to test your OpenCV sym-link, try to import your OpenCV bindings into the keras  virtual environment as well:

Figure 2: Importing OpenCV and Keras together for deep learning with Python.

Figure 2: Importing OpenCV and Keras together for deep learning with Python.

At this point, you should now be able to import Keras and OpenCV into the same Python virtual environment. Take a second to congratulate yourself — you now have all the building blocks in place to start constructing deep neural networks!

Summary

In today’s blog post, I demonstrated how to install the Keras Python package for deep learning with GPU support and without GPU support.

We’ll be using the Keras library extensively in future PyImageSearch blog posts, so I highly encourage you to get Keras installed on your machine, even if it’s just the CPU version — this will enable you to follow along in future PyImageSearch tutorials on deep learning.

Next week, we’ll take another step in our deep learning journey by studying convolutions, what they are, how they work, and how you’re already using them in your computer vision applications (whether you realize it or not).

Be sure to signup for the PyImageSearch Newsletter using the form below — you won’t want to miss when this upcoming post on convolutions goes live!

, ,
